1U rack server

2 x Intel^® Xeon^® 6700P/6500P/6700E processors, each with up to 350 W TDP

32 x memory slots available for DDR5 DIMMs at up to 6400 MT/s or MRDIMMs at up to 8000 MT/s

Hot-swappable drive configurations:
-8/10 x 2.5” SAS/SATA/NVMe drives
-4 x 3.5” SAS/SATA drives*
-16 x E3.S SSDs*
-2 x M.2 SSDs, supporting hardware RAID

RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration

2 x hot-swappable OCP 3.0 NICs, supporting PCIe 5.0, NCSI, and multi-host

Up to 5 x PCIe slots at the rear, supporting PCIe 5.0

8 x hot-swappable counter-rotating fans in N+1 redundancy

900 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy

-The iBMC chip integrates one dedicated management GE port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
-The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management.
-It is optional to configure FusionDirector that enables intelligent, automatic, visualized, and refined management throughout the server lifecycle.

Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and openEuler

Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection

5ºC to 35ºC (41ºF to 95ºF), compliant with ASHRAE Class A1/A2/A3

L-shaped guide rails, adjustable guide rails, and holding rails

43 mm x 447 mm x 798 mm (1.69 in. x 17.60 in. x 31.42 in.)
