    2U 4-Socket Rack Server

    Main application scenarios:

    High performance database (OLAP/OLTP)

    Memory database

    HPC

    High-density virtualization

    • FusionServer 2488H V7 (2488H V7) is a 2U 4-socket rack server designed for the Internet Data Center (IDC), cloud computing, enterprise business, and telecom service applications.
    • It is also ideal for various applications, such as databases, virtualization, and in-memory computing.
    • 2488H V7 features high-performance computing, large-capacity storage, low power consumption, high reliability, easy management and deployment, and high virtualization application density.
    2488H V7, 2U 4-Socket Rack Server

    2U 4-Socket Rack Server

    Main application scenarios

    High performance database (OLAP/OLTP)

    Memory database

    HPC

    High-density virtualization

    • FusionServer 2488H V7 (2488H V7) is a 2U 4-socket rack server designed for the Internet Data Center (IDC), cloud computing, enterprise business, and telecom service applications.
    • It is also ideal for various applications, such as databases, virtualization, and in-memory computing.
    • 2488H V7 features high-performance computing, large-capacity storage, low power consumption, high reliability, easy management and deployment, and high virtualization application density.
    2488H V7, 2U 4-Socket Rack Server

    High-Density Computing Power

    2488H V7, Unparalleled Computing Power

    Unparalleled Computing Power

    4 x 350 W CPUs and 64 x DDR5 DIMMs in 2U space secure
    an industry-leading position

    2488H V7, High-Speed Interconnection

    High-Speed Interconnection

    50% higher UPI speed for interconnection between CPUs provides better performance; supports PCIe 5.0 and 400 Gbit/s NIC interconnection

    2488H V7, Flexible Configuration

    Flexible Configuration

    Supports PCIe 5.0 and multiple standard PCIe slots

    High Reliability and Security

    50% Better Heat Dissipation Capability Than a Single Heat Sink

    Heat pipe remote heat dissipation technology ensures reliable heat dissipation and stronger temperature adaptation

    50% Better Heat Dissipation Capability Than a Single Heat Sink

    66% Less System Downtime

    Unique AI memory fault self-healing ensures stable system running

    66% Less System Downtime

    Efficient Energy Saving

    Saving Energy by up to 8% Compared with the Industry Average

    Saving Energy by up to 8% Compared with the Industry Average

    The unique algorithm is provided for the lowest power consumption of fans and CPUs

    Industry-leading Power Supply Technology for Higher Efficiency

    Industry-leading Power Supply Technology for Higher Efficiency

    Three core technologies improve power and efficiency, enabling the industry-leading power conversion rate and the power loss 12.5% lower than the industry average

    Intelligent Service Awareness, Dynamic Load Adjustment

    Intelligent Service Awareness, Dynamic Load Adjustment

    The CPU working frequency is dynamically adjusted based on the actual service load

    Intelligent O&M

    2488H V7, Intelligent O&M

    Intelligent O&M

    20x Higher Upgrade Efficiency

    20x Higher Upgrade Efficiency

    Automatic version push and upgrades can be completed without onsite attendance

    10x Higher Deployment Efficiency

    10x Higher Deployment Efficiency

    75% streamlined deployment steps are performed by tools

    100% Accuracy for Asset Stocktaking

    100% Accuracy for Asset Stocktaking

    Supports takeover of all vendors' servers, automatic asset location identification, and real-time tracking

    Technical Specifications

    Form Factor

    2U rack server

    Processor

    2 or 4 x 4th Gen Intel® Xeon® Scalable processors with TDP up to 350 W per processor

    Chipset

    Emmitsburg PCH

    Memory

    64 x DDR5 DIMMs

    Local Storage

    Hot-swappable drives configurations:

    • 8 x front 2.5″ SAS/SATA drives

    • 25 x front 2.5″ SAS/SATA drives

    • 4 x front 2.5″ SAS/SATA drives and 8 x NVMe SSDs

    Flash storage: 2 x M.2 SSDs, supporting hardware RAID

    RAID

    RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures;

    RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration

    Network

    Multiple network expansion capabilities

    1 x OCP 3.0 NIC, supporting hot swap

    PCIe Expansion

    Up to 10 x PCIe slots, including 1 x FlexIO slot dedicated for the OCP 3.0 NIC and 9 x standard PCIe slots

    Fan Module

    6 x hot-swappable counter-rotating fans in N+1 redundancy

    PSU

    2 x hot-swappable Platinum/Titanium PSUs in 1+1 redundancy

    • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)

    • 1500 W AC Platinum PSUs

    850 W (input: 100 V to 127 V AC)

    1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC)

    • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC)

    • 1200 W -48 V to -60 V DC PSUs (input: -38.4 V to -72 V DC)

    • 2000 W AC Platinum/Titanium PSUs

    1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)

    2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)

    2150 W Titanium PSUs (input: 230 V to 240 V AC, or 230 V to 288 V DC)

    • 3000 W AC Titanium PSUs

    2500 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)

    2900 W (input: 220 V to 230 V AC, or 200 V to 230 V DC)

    3000 W (input: 230 to 240 V AC, or 230 to 288 V DC)

    Management

    The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.

    • The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management.

    • It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle.

    OS

    FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and openEuler

    Security

    Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection

    Operating Temperature

    5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A1/A2/A3/A4

    Certification

    CE, UL, CCC, FCC, VCCI, and RoHS

    Installation Suite

    L-shaped guide rails, adjustable guide rails, and holding rails

    Dimensions (H x W x D)

    Chassis with 2.5″ drives: 86.1 mm x 447 mm x 898 mm (3.39 in. x 17.60 in. x 35.35 in.)
